Harken – Traction Winch

/// Harken

Overview

The Rigging Winch provides the user with a lightweight, CE certified, portable winch mounted to a sturdy adapter plate. Can be mounted to a tripod. Simple to use and ideal for a diverse range of lifting and load pulling applications. For use with multiple attachments depending on the environment and industry; from ratchet straps, M10 bolts, carabiners, to scaffold clamps. Rigging winch 500 includes: Universal mounting plate, 40.2 Harken winch and Harken 10 inch winch handle.

SKU

INTW500
Retail

$2,350.00

MSRP:

Product Details

Specifications

Minimum line Ø (mm) 8 mm
Minimum line Ø (in) 5/16 in
Maximum line Ø (mm) 12 mm
Maximum line Ø (in) 1/2 in
Weight (kg) 7 kg
Weight (lb) 15.4 lb
Maximum working load (kN) 4.9 kN
Maximum working load (kg) 500 kg
Maximum working load (lb) 1102 lb
Power ratio with 254 mm/10" winch handle 13.5:1/39.9:1
